Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior Wall

Choose our lightweight and fireproof EPS sandwich panels for fast and easy installation of interior and exterior walls. Factory direct pricing.
Request a Quote

PRODUCTS DETAILS

Product Description

Product Description

Thermpanel ® is the brand name of Global Span for sandwich panel. The sandwich panel is with metal faces bonded each side of an insulating core.The sandwich panel is a very important part of envelop system.It serves as external wall,internalpartition,ceiling and roofing. It also serves as external decoration panel and insulated curtain wall panel.It also can be customized as one part of ventilation system and sound absorbing system.
The facing material has become more and more multiple and beautiful in material itself and textures.Global Span supply sandwich panels with different surface texture like plain,metallic,nanometer film and brush.The surface can also be made flat,ribbed,silkline and embossed.
Different insulation cores have different cost and meet different functions.EPS is the most economical one and has high strength and good thermal insulation property. Mineral Wool or Rock Wool is the best fire proof one and widely used in buildings which require strict fire proof standard.PU/PIR is the best thermal insulated core which won great popularity in cold room area.
With the upgrading of new technology,the panel sealing has gone through the period of zero sealing,steel strip sealing,PU sealing,PVC strip sealing,aluminium profile sealing and PVC profile sealing.

Product Parameters
ItemSpecification
Panel Length(mm)500≤L≤12000
  Panel Width(mm)380mm,350mm,950mm,965mm,980mm,1150mm,1180mm,1000mm,1120mm
Panel Thickness(mm)16mm,20mm,50mm,75mm,120mm,150,200mm
Facing Thickness(mm)From 0.25mm-0.8mm
Facing MaterialPPGI,Aluminium Sheet, Stainless Steel Sheet
Surface TextureFlat,Ribbed,Silkline,Embossed
Paint TexturePlain,Metallic,Nanometer film,Brush
            Core ChoicesEPS,PU,PIR,Mineral Wool+PU,Mineral Wool Plus PVC
           Core DensityEPS:8-20 kg/M³,Mineral Wool:80-120 kg/M³,PU:40kg/M³
Zinc CoatingZ20,Z60,Z120, Z275, AZ30, , AZ60,AZ150
Paint TypePVDF,SMP,HDP,PE
Use and Classification

EPS (Polystyrene)Sandwich Panel

Panel Thickness50mm,75mm,100mm,120mm,150mm,200mm
Panel Width950mm,980mm,1150mm
ApplicationIndustrial plant,workshop,warehouse,cold storage,modular prefab house
EPS Density8-20kg/m³


Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior WallRock Woo(Mineral Wool)Sandwich Panel

Panel Thickness
50mm,75mm,100mm,120mm,150mm,200mm
Panel Width950mm,980mm,1150mm
Application Industrial plant,workshop,warehouse,cold storage,modular prefab house
Rock Wool Density80-120kg/m³


Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior WallPU(Polyurethane)/PIR(Polyisocyanate)Sandwich Panel

Panel Thickness50mm,75mm,100mm,120mm,150mm,200mm
Panel Width1000mm,1120mm
ApplicationIndustrial plant,workshop,warehouse,cold room project,modular prefab house
PU/PIR Density 40kg/m


Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior WallPU Sealing Rock Wool/Glass Wool Sandwich Panel

Panel Thickness50mm,60mm,75mm,80mm,100mm,120mm,150mm
Panel Width1000mm,1120mm
ApplicationIndustrial plant,workshop,warehouse,hangaer etc.
DensityRock Wool:120kg/m³,Glass Wool:65Kg/m³,PU:40kg/m³

Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior WallClean Room Sandwich Panel

Panel Thickness50mm,75mm,100mm
Panel Width950mm,980mm,1180mm,other customized width
ApplicationClean room buildings like pharmceutical plant,hospital,lab etc.
Core DensityEPS:16kg/m³,PU;40kg/m³,Rock Wool:80kg/m³ or customized


Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior WallPU Decoration Sandwich Panel

Panel ThicknessWall Panel:16mm,Roof Panel:20mm
Panel WidthWall Panel:380mm,Roof Panel:350mm
ApplicationExternal wall decoration and prefab villa roof
PU Density40kg/m³


Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior WallPerporated Sandwich Panel

Panel Thickness 50mm,75mm,100mm
Panel Width950mm,980mm,1150mm,1180mm
Applicationused in industrial building for sound absorbing purpose
Rock Wool Density80kg/m³,100kg/m³,120kg/lm³


Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior WallReturn Air /Build-in Cable Pipe Sandwich Panel

Panel Thickness50mm,100mm
Panel Width950mm,980mm,1150mm,1180mm
Application Pharmaceutical plant,hospital buildings
Core Density80kg/m³,100kg/m³,120kg/m³/Steel duct,steel pipe or pvc pip

Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior Wall

Company Profile

Global Span is a professional international engineering service company.Our business scope covers project consultancy, design, R&D, delivery and construction.With more than 13 years of international project operation experience and technology reserve, Global Span has formed a perfect one-stop systematic solution service capacity in steel structure construction industry, pharmaceutical manufacturing industry,medical care service,electronic and biotech industry, serving customers from more than 50 countries and regions in the world.
Global Span owns 5 brands. ThermPanel is the brand of sandwich panel.Because thermal insulation is one of the most obvious features. TemBuild is the brand of prefab house,especially the temporary buildings application such as worker camp for office,living.GraceBuild is the brand of customized prefab buildings.Living gracefully is the end of the GraceBuild.SteelSpan is the brand of prefabricated steel structure buildings,which most are large span buildings.CleanBuild is the brand of clean room system.ColorShine is for the metal single panel systems.

To serve global customers and create lasting value is our mission. At Global Span, we treat customers as our partners and value their ideas and experiences. In the early stage of each project, we actively strengthened communication and cooperation with customers and all partners as a team.
Our professional engineers, architects, project managers and construction managers have the expertise and experience to tailor innovative solutions to meet your individual needs wherever you are. We are committed to providing customers with innovative ideas in all aspects of the project, encouraging and promoting innovation in the business, providing industry-leading solutions, and creating world-class projects.


Project Cases
Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior Wall
Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior Wall
Packaging & Shipping

Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior Wall

Customers

Lightweight/Fireproof Fast Install Easy Install EPS Sandwich Panel Wall Panel for Interior Wall Exterior Wall

FAQ
Q1: You are manufacture factory or trading company?
A: We are trading and manufacture factory. And you are welcomed to visit us at any time. The quality control flow and sales team will show you our professionalism. Also you will can get best and most competitive price after visiting us.

Q2: What is the terms of delivery?
A: EXW, FOB, CIF, CFR, DDU

Q3: What is the terms of packing?
A: Generally, we pack our goods in bundles or coils with rods or belts, we could also pack the goods as the customers'
requirement.

Q4: What is your delivery time?
A: For stocks, we could transport the goods to loading port within 7 days after we received your payment. For production period,
it usually takes about 15 days - 30 days after receiving the deposit.

Q5: Could you produce according to the samples?
A : Yes, we could customer-made by your samples or technique drawings, we could build the mold and fixtures.

Q6: Could you provide the compliment samples?
A: Yes, we provide the free samples if available in stocks, the transportation fee is borne by buyer.

Q7. What is your terms of payment?
A: Normally 30% T/T as the upfront deposit, 70% before delivery. We will show you the photos of products and package before you pay the balance.

Q8: How to contact you?
A: You can contact us by email, phone, Alibaba TM, WhatsApp, Skype, Viber and so on 24*7 and you will get reply within 8 hours.
