- Overview
- Our Advantages
Basic Info.
Model NO.
KM-01
Function
Special Cement
Heat of Hydration
Moderate Heat
Fineness
>60um
Technique
Dry Process
Color
White
Project Solution
Graphic Design, 3D Model Design, Total Solution Fo
Product Name
Grc,,Cast Stone,Precast Concrete
Finish
Warmholewood and Stone etc
Sizes
Can Be Customized
Design
Can Be Customized
Standard
Ast
After-Sale Service
Online Technical Supportonsite Installation
Application
Residential and Commercial Buildings
Transport Package
Carton; Pallet; Wooden Cartoon
Specification
Packed in wooden cases, conforming to container si
Trademark
KM
Origin
China
HS Code
6811899000
Product Description
Properties& Characteristics | Stone | Aluminium Unitized Panel | Terra-Cotta Panel | GRC |
Weight | 60-100KG/SQM | 10-15KG/SQM | 30-60KG/SQM | 30-70KG/SQM |
Moldeling & Function | Suit to flat and arc panel,difficult in moulding complex profile and double-curved panel | mainly flat panel,difficult in moulding complex profile and double-curved panel | mainly flat panel,difficult in moulding complex profile and double cruved panel | can be moulding to any profile ,easy to realize every kind of complex profile |
Dimension&size | applicable to small size panel,single panel unit less then 1sqm | applicable to middle size panel,single panel unit less then 2sqm | applicable to small size panel,single panel unit less then 1sqm | applicable to large size panel,single panel up to 40sqm or above |
Surface Texture | natural | metallie | siatered | textured and colorful |
Environmental Protection | non-renewable resource,harmful to environment | high energy-consumption,pollution to surroundings | high energy-consumption,pollution to surroundings | low energy-consumption,non pollution |
Safety(Failure statue) | brittle and fragile,no omen when brittle failure | apt to derformation,have omen when ductile failure | brittle ,no omen when brittle failure | Good ductile,not easy to deform,have omen when ductile failure |
Durability | natural material,good durability | metallic material,general durability | inorganic materials,good durability | inorganic materials,better durability |
Fixing Method | hung directly or fixing with bolt from back side | riveting/boading | hung directly or fixing with bolt from back side | hung directly/fixing with bolt/connect with backing steel frame |
Modulus of Rupture | above 8MPA | 50-125mpa | above 9mpa | above 18mpa,good ductility |
FAQ
1. What is the largest size for GRC?
Without use of bearing steel frame, the maximum size is 1.2m*2.4m; in the case of bearing steel frame, the maximum size is 2.4*13m. 2. What are the parameters of the GRC?
The density of GRC is 1.8~2.0T/m³; service life of GRC is 50years; fair rating A1; bending strength greater than 8~30Mpa; the compressive strength is greater than 40~80Mpa; water absorption is less than 14%, our company's test result is less than 9%, resistance to freezing and thawing is at minus 25 degrees, and 50 tests, superior to the 25 tests required by the specification; shock resistance is .10~30 N mm /mm² .
3. What is the different between GRC, GRG, GRP UHPC?
GRC: GRC is a composite material composed of cement, sand, water, glass fiber, additives and other aggregates and mixtures. Cement and water hydration reaction after the hardening, the formation of cementitious cement stone, sand (or other aggregates) firmly cemented together, and cement anchor glass fiber, formed a material with good performance. Sand fills and frames GRC, and glass fiber strengthens it. Mainly used for outdoor decoration.
4.How can i get quotation?
As GRC products are mostly customized according to clients designs ,so you can provide us your house design drawings if you have,Ideally if you can provide design drawings and bill of quantity.If you do not have designs ,you can send us picture to show designs you want and also tell us the sizes for the designs ,we can also provide approximate quotation.
5.Do you provide installation?
Yes ,we can provide installation if all terms are suitable .And if the quantity is small ,we can provide installation guidance drawings and video to teach you how to install.
